Specifications
Engine 200cc
Transmission Belt drive
Drive type Belt
Belt and/or chain size Belt: 835*20*30
Starter System Electric start
Fuel system EFI
Brakes (Front/Rear) Disc/Drum
Tire size(Front/Rear) 120/70-12?120/70-12
Wheel size and type(Front/Rear) 12, Alloy Wheel
Fuel Capacity (in liters) 8.5L
Gear oil type and capacity( in liters) SGL-4 85W-90 140mL
Battery 12V/6A
Lights LED lights
Suspension(Front/Rear) Trailing link coilover shocks / single shock
Dimensions(in inches) Assembled(LxWxH):71.89x30.94x42.8, crated(LxWxH): 74.8x22.83x33.86, seat height 30.71, wheelbase:50.79
Weight 450lbs
Weight capacity 353lbs
Ground clearance (in inches) 4.3
Assembly required Front wheel, front fender, handlebars, mirrors, battery, Rear shock absorber
Special features Include: speedometer, light, odometer, Smart lock
EPA approved EPA approved
