KEY FEATURES:
STEREO SURROUND ; MP3
KEYLESS START
ADAPTIVE SUSPENSION ENGINE SYSTEM, LESS VIBRATION, CREATING GREATER RIDING ACCELERATION AND COMFORT
CBS LINKAGE BRAKE SYSTEM
CALIFORNIA APPROVED
SPECIFICATION
Engine
Engine model: GY6 JL Engine
Engine Type: 1-Cylinder.4-Stroke.air-cooled
Displacement: 168CC
Ignition: CDI EFI
Start method: Electric start; start without key
Compression ratio: 9.5:1
Certified: EPA & DOT
Motorcycle Body
Brakes: Front: disc/Rear: disc
Front Suspension: Telescopic
Rear Absorber: Spring hydraulic
Wheel Base: 1370mm
Tire Size ; Front: 130/70-13; Rear: 130/70-13
Wheel Atmosphere: Front & Rear; 220/250kPa
Fuel mode: Gasoline
Fuel Supply Way: EFI
Dimension: 1920*675*1070mm
NW/GW(kg): 91kg/116kg
Performance
Max Power: 8.3kw / 7000r/min
Max. Torque: 12Nm / 5500r/min
Max Load: 150kg
Max Speed: 85km/h
Fuel tank capacity: 5L
Battery: 12V7Ah
Other Features: MP3 & USB
