SPECIFICATIONS:
Engine Type: 110CC Single Cylinder, 4-Stroke
Displacement: 107cc
Max Torque: 6.9N.m/6,500 ± 500r/min (N.m/r/min)
Max Power: 4.8kW/8,000 ± 500r/min (kW/r/min)
Bore Stroke: 52.4 x 49.5mm
Ignition: CDI
Starting System: Electric
Battery: 12V, 4Ah
Clutch: Automatic
Transmission: Chain, Rear Wheel Drive
Brakes Front/Rear: Drum/Hydraulic Disc
Tires Front/Rear: 15 x 5-6 /15 x 5-6
Fuel Capacity: 0.54 gallons / 2.06L
Weight: G.W./N.W154 lbs/176 lbs
Max Load: 145 lbs / 65 kg (rider, all cargo and accessories)
Wheelbase: 860mm
Dimensions: 1,275 x 930 x 900mm
Height to Seat: 440mm
Min. Ground Clearance: 85 mm
